Features
A standard LED-flashing-stripe-display unit, which functions bar length, bar material change, alarm display while feeding/machining being easy to monitor ( patented).
A hi-end PLC controller is with completed software concept and module-assembly electrical cabinet.
A HMI display unit functions international languages being easy to set up, user friendly, showing alarm message to troubleshoot.
A loading system features speed, accuracy, and simple.
A mobile remote control box is user friendly to operate with.
PU guide channel sets of BWG model are easy & quick to changeover.
Powder-metallurgy guide channel sets of EWG model are super durable to run guarantying to provide a longevity ever.wear-resistance, high rigidity, accuracy and durability.
Free adjustment of clamping device while bar material is changed.
Specifications
| Model |
BWG / EWG
|
| Specifications |
2.5M / 3.0M / 3.6M
|
|
BWG PU
Guide Channel |
11mm，14mm，17mm，19mm，21mm，23mm，25mm，27mm
|
|
BWG Bar Diameter
|
3~10mm，3~13mm，3~16mm，3~18mm，5~20mm，5~22mm，5~24mm，5~26mm
|
| EWG Steel Guide Channel |
11mm，13mm，17mm， 21mm，24mm，27mm
|
| EWG Bar Diameter |
3~10mm，3~12mm，3~16mm，5~20mm，5~23mm， 5~26mm
|
| Bar Capacity |
10mm(3/8”)X23pcs
|
| Bar Length |
2.5M:2700mm，3.0M:3200mm，3.6M:3800mm
|
| Machine Weight |
2.5M–450kg，3.0M–500 kg，3.6M–650 kg
|
| Air Pressure |
6kgf/cm² 70psi
|
| Transmission |
SERVO MOTOR
|
| Lubricant |
FK ISO VG68，FK HYDRAULIC OIL 68
|
| Capacity |
38L(10 GALLON)
|
| Power Consumption |
630W
|
| Powre Supply |
3φx220V 50/60Hz
|
